Triumph XRX User Manual

General Information
78
Rider's Seat
1. Rider's seat
To remove the rider's seat, remove the
pillion seat (see page 76).
Grasp the rider's seat on either side, and
slide it rearwards and upwards for
complete removal from the motorcycle.
To refit the seat, engage the seat's front
rail into the bracket at the rear of the
fuel tank and lower the rear rail in to the
rear brackets. Push down firmly on the
rear of the seat. Refit the pillion seat
(see page 76).
Rider's Seat Height Adjustment
1. Rider's seat
2. Front seat height adjuster
3. Pillion seat height adjuster
4. Low seat height position
(rear shown)
5. High seat height position
(rear shown)
The rider's seat is adjustable for height
by approximately 25 mm.
To adjust the rider's seat:
Remove the rider's seat (see page 78).
Reposition both seat height adjusters to
the higher or lower position as required.
Ensure both adjuster rails are fully
engaged in their brackets on the seat.
Refit the rider's seat (see page 78).
Warning
The rider's seat is only correctly
retained and supported once the
pillion seat is correctly fitted. Never
ride the motorcycle with the pillion
seat detached or removed, as the
front seat will not be secure and may
move.
A loose or detached seat could cause
loss of motorcycle control and an
accident.
1
cgig
2
4
5
3
cgih
1

Triumph XRX Specifications

General

Transmission	6-speed
Engine Type	Liquid-cooled, in-line 3-cylinder
Front Brake Calipers	Brembo Stylema 4 piston radial monobloc calipers
Rear Brake Calipers	Brembo single piston sliding caliper
Seat Height	830 mm (32.7 in)
Fuel System	Fuel injection
