10
Fig. 9
3. Snap the clip on to the support fittings on the front
or back of the handle. Clip to the front portion of the
handle when using the unit as a blower, and clip to
the back portion of the handle when using the unit as
a vacuum (Fig. 8).
4. While standing in the operating position, adjust the
length to fit the operator’s size. Pull the tab to
lengthen, pull the strap to shorten (Fig 9).
INSTALLING THE SHOULDER HARNESS (Optional)
The shoulder strap is an optional accessory.
1. Push the strap through the center of the buckle.
2. Pull the strap over the cross bar and down through
the slot in the buckle (Fig. 7).
Fig. 7
Clip
ASSEMBLY INSTRUCTIONS
To avoid serious
personal injury,
never attempt to start the unit when
standing with the unit clipped to the
shoulder strap. Always follow the starting
procedures as described in the Starting/
Stopping Instructions section.
WARNING:
Attach Here for
Blowing
Attach Here for
Vacuuming
Fig. 8
