TVS NTORQ 125 User Manual

61
Replace the brake pads as a set, if the wear indicator
shows beyond the wear limit.
Caution
Brake pad wear indicator (Disc brake)
Check for the wear of brake pads visually. If the brake
pads wear is found beyond the wear indicator groove
as shown in the figure, replace the brake pads as a
set with a new one.
Rear brake (Drum brake)
1. Measure the free play of the rear brake lever at
the lever end as shown in the figure.
2. Free play of brake lever before the engagement
of brake should be between 10 ~ 15 mm.
3. If the measured distance is more than the limit,
adjust the nut provided at the rear wheel end to
obtain the correct play.
Check front brake (drum brake type) and rear brake
play periodically. However the brake play needs to be
adjusted more frequently depending upon the usage.
Warning
Disc brake SBS cable need to be adjusted incase if
rattling is found in both brake levers.
Warning

TVS NTORQ 125 Specifications

General

Displacement	124.8 cc
Max Torque	10.5 Nm @ 5, 500 rpm
Fuel System	Fuel Injection
Transmission	CVT
Front Brake	Disc
Rear Brake	Drum
Kerb Weight	118 kg
Front Tyre	100/80-12
Rear Tyre	110/80-12
Starting Method	Electric Start
Tyre Type	Tubeless
Seat Height	770 mm
Ground Clearance	155 mm
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Front Suspension	Telescopic
Fuel Tank Capacity	5.8 liters
Wheelbase	1285 mm
Rear Suspension	Coil Spring, Hydraulic Damped
