TVS NTORQ 125 User Manual

77
TECHNICAL SPECIFICATIONS
MANUFACTURER : TVS MOTOR COMPANY LIMITED
P.B. No1, Bythahalli, Kadakola post, Mysore - 571 311, India.
ENGINE
Type : Single cylinder, SOHC,
4 stroke, air cooled, spark
ignition engine
Cylinder bore : 53.5 mm
Stroke : 55.5 mm
Piston displacement : 124.79 cc
Compression ratio : 9.8 : 1
Carburettor : Keihin CT5 (VM20) with
Autochoke
Air filter : Dry paper filter with dry foam
Oil filter : Wire mesh
Lubrication system : Forced wet sump
Maximum power in kW : 6.9 @ 7500 rpm (9.4 PS)
Maximum torque in Nm : 10.5 @ 5500 rpm
Maximum speed : 95 km / h
Engine idling rpm

: 1600 ± 100 rpm
Starting system : Electric starter / kick starter
Emission norms : BSIV
TRANSMISSION
Clutch : Dry - Centrifugal clutch
Primary transmission : CVT (Continuos Variable
Transmission)
Primary reduction : 2.6 to 0.82
Secondary reduction : 9.085
CHASSIS
Overall length : 1865 mm
Overall width : 710 mm
Overall height : 1160 mm
Ground clearance : 155 mm (unladen)
Wheel base : 1285 mm
Kerb weight (with toolkit : 115 kg (Drum)
and 90% of fuel) : 116 kg (Disc)
Pay load : 130 kg
Maximum laden weight : 245 kg (Drum)
: 246 kg (Disc)
Frame : Under bone tubular frame
Front suspension : Telescopic hydraulic
Rear suspension : Toggle link, gas filled hydraulic
damper

TVS NTORQ 125 Specifications

General

Displacement	124.8 cc
Max Torque	10.5 Nm @ 5, 500 rpm
Fuel System	Fuel Injection
Transmission	CVT
Front Brake	Disc
Rear Brake	Drum
Kerb Weight	118 kg
Front Tyre	100/80-12
Rear Tyre	110/80-12
Starting Method	Electric Start
Tyre Type	Tubeless
Seat Height	770 mm
Ground Clearance	155 mm
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Front Suspension	Telescopic
Fuel Tank Capacity	5.8 liters
Wheelbase	1285 mm
Rear Suspension	Coil Spring, Hydraulic Damped
