MS842P Quick Start Guide
How can we help you?
How can we help you?
The MS842P is a plug-and-play wireless laser scanner. It does
not require a driver and should be recognized as a generic HID
device by your computer, similar to a standard keyboard. This
allows you to scan into any eld that you could normally type
into.
Unitech’s professional support team is available to quickly
answer questions or technical-related issues. Should equipment
issues occur, please contact a Unitech Service Representative
at (800) 861-8648 or visit us.ute.com for more information.
Now scan these barcodes in the following order: 1, 0, 0, 9. Please make sure the “x” marker is in the center of the barcode as you scan.
Tab mode cont.
Scan here to enter your settings. You are now in Tab Mode.
Tab mode cont.
Enter
Scan here to return to the default Enter Mode from Tab Mode. Data will
now jump to the next line as you scan.
Enter Mode

Unitech MS842P Specifications

General

Type	Handheld bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Tilt reading angle	-60 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 25 (IR 2 of 5), Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, MSI, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
USB version	2.0
Wireless range	10 m
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Product color	Black, Grey, Yellow
Housing material	-
International Protection (IP) code	IP54
Battery life	10 h
Charging time	4 h
Input voltage	5 V
Battery capacity	1620 mAh
Power consumption	400 mA
Power source type	DC
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	74 mm
Width	89 mm
Height	176 mm
Weight	200 g
Base dimensions	73 x 95 x 200 mm
