Unitech MS912 Manual

Enable scanning MSI barcodes
Transmit AIM Code ID (allows ZiiZii to detect symbology)
4 Pair the scanner to an Android device
1. Ensure the scanner is powered on and configured for SPP mode.
2. Open Settings, locate Bluetooth, and choose “Pair a device”. The menus are arranged differently
depending on the Android device.
3. Tap “Wireless Scanner” when it appears in the discovered devices.
4. Wait for the scanner to connect.
5. Open ZiiZii, and choose “Settings” from the main screen. Select “Generic SPP scanners” as
the Bluetooth scanner module. The scanner should now connect, and a system notification will
be available (swipe down from the top of the screen to see notifications) saying “1 Bluetooth
scanner connected” while building orders.
5 Android scanning help
1. Remember that all scanners must be unpaired, both on the scanner itself, and the device.
2. Android devices require all scanners to be in SPP mode before pairing with the device.

Unitech MS912 Specifications

General

Type	Handheld bar code reader
Sensor type	CCD / CMOS
Scanner type	1D
Read rate (max)	240 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Wireless range	10 m
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black, White
Housing material	ABS synthetics
Battery voltage	3.7 V
Power source type	Battery
Number of reads per charge	5000
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %
Cables included	USB

Weight and Dimensions

Depth	72 mm
Width	30 mm
Height	20 mm
Weight	30.2 g
