Utax P-4030DN Service Manual

2LV/2L1/2L2/2MS/2MT
1-4-7
4211 Ejetct sensor stay jam The eject sensor (ES) does not turn off during
paper feed from cassette 1.
I or L
4212 The eject sensor (ES) does not turn off during
paper feed from cassette 2.
I or L
4213 The eject sensor (ES) does not turn off during
paper feed from cassette 3.
I or L
4214 The eject sensor (ES) does not turn off during
paper feed from cassette 4.
I or L
4215 The eject sensor (ES) does not turn off during
paper feed from cassette 5.
I or L
4218 The eject sensor (ES) does not turn off during
paper feed from duplex section.
I or L
4219 The eject sensor (ES) does not turn off during
paper feed from MP tray.
I or L
4301 Duplex sensor 1 non arrival
jam
The duplex sensor 1 (DUS1) does not turn on dur-
ing paper feed from cassette 1.
J
4302 The duplex sensor 1 (DUS1) does not turn on dur-
ing paper feed from cassette 2.
J
4303 The duplex sensor 1 (DUS1) does not turn on dur-
ing paper feed from cassette 3.
J
4304 The duplex sensor 1 (DUS1) does not turn on dur-
ing paper feed from cassette 4.
J
4305 The duplex sensor 1 (DUS1) does not turn on dur-
ing paper feed from cassette 5.
J
4309 The duplex sensor 1 (DUS1) does not turn on dur-
ing paper feed from MP tray or bulk feeder.
J
4401 Duplex sensor 2 non arrival
jam
The duplex sensor 2 (DUS2) does not turn on dur-
ing paper feed from cassette 1.
K
4402 The duplex sensor 2 (DUS2) does not turn on dur-
ing paper feed from cassette 2.
K
4403 The duplex sensor 2 (DUS2) does not turn on dur-
ing paper feed from cassette 3.
K
4404 The duplex sensor 2 (DUS2) does not turn on dur-
ing paper feed from cassette 4.
K
4405 The duplex sensor 2 (DUS2) does not turn on dur-
ing paper feed from cassette 5.
K
4409 The duplex sensor 2 (DUS2) does not turn on dur-
ing paper feed from MP tray or bulk feeder.
K
4418 Duplex sensor 2 stay jam The duplex sensor 2 (DUS2) does not turn off dur-
ing paper feed from duplex section.
K
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper jam location (see page 1-4-1).

Utax P-4030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	32 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, IBM ProPrinter XL24E, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Thicker paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Compatible memory cards	SD
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Certification	GS/TÜV, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	3 W
Power consumption (standby)	13.3 W
Power consumption (printing)	618 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
