4: Normal
Length 1 byte
Read Write
Description: The common mode for the Actual target
BLOCK_ERR
[Diagnostic]
Length 2 byte
Read Only
Description: This parameter reflects the error status
associated with the hardware or software components
associated with a block. It is a bit string, so that
multiple errors may be shown.
PV
[Process]
[Trends]
1: Process Variable
Length 4 byte
Read Only
Description: The process variable read from the
hardware, addressed in the Modbus Transducer block
2: Process Variable Status
Length 1 byte
Read Only
The process variable status
SP
[Process]
1: Value
2: Status
Length 1 byte
Read Write
The set point variable status
Description: The analog set point of this block.
OUT
[Process]
Length 4 byte
Read Only
Description: The block output value calculated as a
result of the block execution.
CAS_IN
[Process]
1: Value
2: Status
Length 1 byte
Write
The set point variable status
Description: This parameter is the remote setpoint
value which must come from another Fieldbus block,
or a DCS block through a defined link.
BKCAL_OUT
[Process]
1: Value
2: Status
Length 1 byte
