VAT 612 Series User Manual

OPERATION
Series
612
86/116 Edition 2018-08-20 605262EE
5.6.5 Safety mode
By means of an external switch (see connection diagrams «Electrical connection») the motor power
supply can be interrupted. In this case the valve enters the ‘safety mode’. This motor interlock prevents
the valve from moving (e.g. maintenance work). Data reading from the control unit remains possible.
When motor interlock is active during power up the valve directly enters the ‘safety mode’ and is not able
to synchronize. Display shows ‘D C’ or ‘D999’. In this case synchronization cycle will be done when
motor interlock is deactivated. Then Display shows ‘INIT’ for a moment followed by ‘SYNC’.
When ‘safety mode’ is entered from operation (i.e. pressure control mode), the unit will automatically
switch to position control mode and remain at current position. Once motor interlock is deactivated the
unit remains in position control mode.
5.6.6 Service indication
This product is able to indicate that the valve unit needs to be cleaned, or an obstruction is present.
A service request is indicated when the control unit detects that motor steps are apparently not effective.
This may happen when the valve unit is heavily contaminated. These ‚lost‘ steps are recognized and will
be repeated to attempt target position in the short term. But in the medium term the valve unit requires
cleaning or inspection. ‘Service request’ (SR) would be indicated on the display or could be read via
remote operation. Refer to «Display information» for details.
5.7 Operation during power up
Valve position
before power up:
Reaction of valve:
Any
Valve runs a synchronization cycle (close-open-close) to detect the limit
stops. This cycle is performed with reduced torque (80%). Display shows
configuration of product until synchronization cycle is done. Refer also to
chapter «Display information».
5.8 Behavior in case of power failure
Valve position
before
power failure:
Reaction of valve:
Without Power Failure Option (PFO)
612 . . - . . G . - . . . .
612 . . - . . A . - . . . .
612 . . - . . T . - . . . .
612 . . - . .
V
. - . . . .
With Power Failure Option (PFO)
612 . . - . . H . - . . . .
612 . . - . . C . - . . . .
612 . . - . . U . - . . . .
612 . . - . .
W
. - . . . .
Any Valve remains at current position. Valve will close or open depending
on valve configuration 1).
Default is not defined.
Display indicates F.
1) Provide that battery pack of the VAT controller is charged. Charging time after power up is 2 minutes
max..
All parameters are stored in a power fail save memory.
