4.1 Additional CC-Link warning
Failure detection with CPA or
CV software
Check Action
Network failure: No CC-Link
communication is active
(warning 8)
- CC-Link cable ok?
- Connection to master ok?
- Check CC-Link cable.
- Check the CC-Link connection to master.
If you need any further information, please contact one of our service centers. You can find the addresses on our website:
http://www.vat.ch
