15
20 21 22 23
17 18
16 19
Warning display
If the acoustic alarm sounds, one of the three warning
lamps (16-18) on the instrument panel starts to flash
to indicate the source of the alarm.
16. Engine coolant temperature too high.
IMPORTANT! If the alarm sounds: Reduce engine
speed to idle (neutral). Stop the engine if the
temperature does not drop. Investigate and correct
the malfunction.
17. Low oil pressure.
IMPORTANT! If the alarm sounds: Stop the
engine immediately and investigate.
18. Generator not charging.
19. Indicator lamp Comes on when the glow plugs are
activated.
Check that the warning lamps are operating before
starting the engine according to the description of the
relevant instrument panel.
Extra warning display
If the acoustic alarm sounds, one of the four warning
lamps starts to flash to indicate the source of the
alarm. The extra warning display is an accessory.
20. Not used.
21. Low coolant level. Top up to correct level before
starting.
22. Water in extra fuel pre-filter. Drain off water in
filter. See instructions in the chapter Maintenance.
23. Extra alarm for an optional function.
7741986 - Downloaded from www.volvopenta.com 06/10/2006 13:10:27
