Wayne P250 User Manual

Electrical power supply: 120V/60Hz 1 Ph. MOUNTING: Adjustable flange is standard.
P250
P265
Maximum Input
250,000 Btu/hr (73 kW)
200,000 Btu/hr (59 kW)
Minimum Input
15,000 Btu/hr (4.4 kW)
15,000 Btu/hr (4.4 kW)
Turndown
5:1
5:1
Fuels
Natural & L.P. Gas
Natural & L.P. Gas
Maximum Inlet
Pressure
14” w.c. Natural
14” w.c. LP
14” w.c. Natural
14” w.c. LP
Minimum Inlet
Pressure
5.5” w.c. Natural
11” w.c. LP
5.5” w.c. Natural
11” w.c. LP
WAYNE COMBUSTION SYSTEMS
801 GLASGOW AVE.
FORT WAYNE, IN 46803
PHONE: (260) 425-9200
(855) WAYNECS
(800) 443-4625
FAX: (260) 424-0904
www.waynecombustion.com
iHEAT SYSTEM
Manual 64659-001| Revision A | Publication Date: 07/06/18
NOTE: Dimensions in () are informational only. English values take priority.
READ THIS MANUAL BEFORE USING THIS PRODUCT. FAILURE TO FOLLOW THE INSTRUCTIONS AND SAFETY
PRECAUTIONS IN THIS MANUAL CAN RESULT IN SERIOUS INJURY OR DEATH. KEEP THIS MANUAL FOR FUTURE
REFERENCE. INSTALLER: LEAVE THIS MANUAL WITH THE END USER.
INSTALLATION OF THE BURNER MUST BE DONE BY A QUALIFIED INSTALLER IN ACCORDANCE WITH REGULATIONS
OF THE NATIONAL FUEL GAS CODE ANSI Z223.1/NFPA54, AND IN COMPLETE ACCORDANCE WITH ALL LOCAL
CODES AND AUTHORITIES HAVING JURISDICTION.
A QUALIFIED INSTALLER IS THE PERSON WHO IS RESPONSIBLE FOR THE INSTALLATION AND ADJUSTMENT OF THE
EQUIPMENT AND WHO IS LICENSED TO INSTALL GAS-BURNING EQUIPMENT IN ACCORDANCE WITH ALL CODES
AND ORDINANCES.
CSA CERTIFICATE NUMBER: 1156769

Wayne P250 Specifications

General

Brand	Wayne
Model	P250
Category	Burner
Language	English
