Service manual Functional verification 21
Printer
1. Put the monitor into Service Mode.
2. Verify that the printer has paper.
3. Press . Verify that a settings report prints, and that it contains no printed anomalies
and no missing or faded sections.
4. After 2 seconds of printing, verify that the current draw is no more than 2.5A above
the baseline current recorded in step 2 of the verification test “Baseline current
draw” on page 13.
5. Exit the Service Mode.
Note
This test is to be performed only as part of a complete functional verification
procedure.
Note
With a new roll of paper, the first line might be faded. This does not indicate a
problem.
Note
The settings report (as shown in the example below) contains a calibration record,
user record, hardware status record, and software versions record.
• The calibration record includes manufacturing configuration data: monitor
serial number, set parameters, and language.
• The user record includes user-configurable settings: alarm limits, patient type,
parameter modes/units, auto interval, tone volume, and others.
• The hardware status record shows the hardware revision number, the battery
voltage level, the total number of NIBP monitoring cycles completed on the
monitor, and the total number of hours of operation of the monitor.
• The software versions record indicates the software version numbers of the
main board, SpO
2
and Temperature options (if present), and NIBP.
