Xantrex RV Series Inverter/Charger Owner’s Manual
35
User Menu
The following is the information normally available to the system users.
Meters Menu
To ENTER and EXIT the METERS MENU press the right Menu Item button for five seconds
AC Output:
0 VAC
Pass-thru Amps:
0 amps AC
Solar Panel:
0 amps DC
Battery:
12.6 volts DC
DC Current:
0 amps DC
AC Input:
0 VAC 0 Vpk
Use the Menu Item buttons to move up and down vertically
Use the SET POINT buttons to move left horizontally
Values in left-most column are the DEFAULT values at startup
System Status:
Oload/Less Load
System Status:
Otemp/Less Load
System Status:
Lobat/Start Chrg
System Status:
Float Charging
System Status:
Absorption Chg
System Status:
Bulk Charging
System Status:
Inverting
System Status:
Searching
System Status:
Waiting for AC
System Status:
Hibat/Stop Chrg
Bat State of Chg:
E F
Bat State of Chg:
0 % of Full
Time Left to Run
0.0 Hours
Time Left to Chg:
0.0 Hours
