12 Connecting the LP hose
To allow for proper operation of the inflator it must be connected to the LP port of the 1st stage of the
regulator using the LP hose supplied with the BC.
1), and then put the nozzle onto the quick connector (step 2), as presented in the pictures below:
LP hose connection using the 1
st
stage of the regulator must be made to the low pressure (LP) port only.
Connection to the HP port may result in serious injuries as well as damage to the equipment.
Fig. 25. LP hose connection (step 1)
Fig. 26. LP hose connection (step 2)
The inflator supply pressure value should be between 6 and 15 bar. Before connecting the inflator to the
LP hose, make sure that the pressure from the regulator is within this range.
