Xerox WorkCentre 3325 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-25
Parts List 3.2 Bypass Tray
Item Name Part Number
0 Bypass Tray 130N01676
1 Taptype Screw
2 Idle Holder MP
3 Roller Cover
4 Idle Roller
5 ETC Pin
6 CS Spring
7 Lower MP
8 Empty MP Actuator
9 Lower MP Guide
10 Bypass Tray Paper Empty Sensor 130N01574
11 Cassette Pad RPR
12 TS Spring
13 CS Spring
14 Retard Roller Cassette (Retard Roller) (includes 15, 16) 022N02677
15 Torque Limiter Coupler
16 TL Rubber
17 Retard Shaft Holder 006N01347
18 Upper MP
19 Arm MP Actuator
20 Upper MP Guide
21 Bush PMO
22 MP Stopper
23 ES Spring
24 Pick Up MP (Bypass Tray Pick Up Assembly) 130N01675
25 MP Collar
26 Idle Pick Up Gear
27 Joint Gear
28 Joint2 MP Gear
29 Shaft Holder
30 Pick Up MP Housing
31 Pick Up Clutch Sub PMO
32 Pick Up Rubber
33 Pick Up Sub Shaft
34 Pick Up MP Shaft
35 MP Clutch Sleeve
36 MP Sleeve
37 TS Spring
38 Plain Washer
