Xiaomi Mi Electric Scooter 1S User Manual

1
EN
2
EN
4
EN
3
EN
Connect with Mi Home / Xiaomi Home App
The scooter without being activated will keep beeping
when turned on, and its speed is limited to 10 km/h.
Scan the QR code to download and install the app.
Open Mi Home / Xiaomi Home app.
* The app is referred to as Xiaomi Home app in Europe (except for Russia). The name of the app displayed on your device should be taken as the
default.
Tap "+" on the upper right, and then follow prompts to
add your device.
5
EN
6
EN
Note: The version of the app might have been updated, please follow the instructions based on the current app version.
Follow the on-scr
een instructions in the app to activate
your scooter for the first use.
The beeping sound will not stop until the scooter
is activated.

Xiaomi Mi Electric Scooter 1S Specifications

General

Type	Classic scooter
Foldable	Yes
Motor type	Brushless
Wheels type	Solid wheels
Cable length	2 m
Maximum speed	25 km/h
Product color	Black
Motor position	Front wheel
Wheel material	Rubber
Maximum gradient	14 °
Number of wheels	2 wheel(s)
Rear brake system	Disc brake
Display technology	LCD
Recommended gender	Any gender
Maximum load weight	100 kg
Displayed parameters	Battery status, Distance traveled, Gear indicator, Operating mode, Speed
Recommended age (max)	50 yr(s)
Recommended age (min)	16 yr(s)
Recommended height (max)	200 m
Recommended height (min)	120 m
Storage temperature (T-T)	-20 - 45 °C
Suitable for surface type	Asphalt
Front tire size (imperial)	8.5 \
Operating temperature (T-T)	-10 - 40 °C
Distance per battery charge (max)	30 km
International Protection (IP) code	IP54
Motor power	250 W
Battery type	NE1003-H
Charging time	5.5 h
Output current	1.7 A
Output voltage	42 V
Battery voltage	36 V
AC input voltage	100 - 240 V
Battery capacity	7.65 Ah
AC input frequency	50 - 60 Hz
Instantaneous power (max)	500 W
Package type	Box
Seat included	No

Weight and Dimensions

Depth	430 mm
Width	1080 mm
Height	1140 mm
Weight	12500 g
Folded height	490 mm
