Specifications
GENERAL
Frequency Range: RX: 28.000 - 29.700 MHz, 50.000 - 54.000 MHz,
108.000 - 180.000 MHz, 320.000 - 480.000 MHz,
700 - 985 MHz (Cellular Blocked)
TX: 28.000 - 29.700 MHz, 50.000 - 54.000 MHz,
144.000 - 146.000 MHz (or 144.000 - 148.000 MHz),
430.000 - 440.000 MHz (or 430.00 - 450.000 MHz)
hannel Steps: 5/10/12.5/15/20/25/50 kHz
odes of Emission: F3, F2, F1
ntenna Impedance: 50-Ohms, unbalanced (Antenna Duplexer built-in)
requency Stability: ±5 ppm @ 14° F ~ +140° F (–10 °C ~ +60 °C)
perating Temperature Range: –4° F ~ +140° F (–20 °C ~ +60 °C)
upply Voltage: 13.8 VDC (±15%), negative ground
urrent Consumption (Approx.): RX: 0.5 A (Squelched)
TX: 8.0 A (50/430 MHz), 8.5 A (29/144 MHz)
ase Size (W x H x D): 5.5” x 1.6” x 6.6” (140 x 41.5 x 168 mm) (w/o knobs & connectors)
eight (Approx.): 2.2 lb (1 kg)
RANSMITTER
utput Power: 50/20/10/5 W (29/50/144 MHz),
35/20/10/5 W (430 MHz)
Modulation Type: Variable Reactance
Maximum Deviation: ±5 kHz (50/144/430 MHz),
±2.5 kHz (29 MHz)
Spurious Radiation: Better than –60 dB (29 MHz: Better than –50 dB)
Modulation Distortion: Less than 3%
Microphone Impedance: 2 kW
DATA Jack Impedance: 10 kW
RECEIVER
Circuit Type: Double-conversion superheterodyne
Intermediate Frequencies: 45.05 MHz/450 kHz (Left band),
47.25 MHz/450 kHz (Right band)
Sensitivity (for 12dB SINAD): Better than 0.2 µV
Squelch Sensitivity: Better than 0.16 µV
Selectivity (–6dB/–60dB): 8 kHz/30 kHz (50/144/430 MHz),
6 kHz/30 kHz (29 MHz)
Maximum AF Output: 2 W @ 8 W for 5% THD
AF Output Impedance: 4-16 W
Specifications are subject to change without notice, and are guaranteed within the 29, 50, 144, and 430 MHz amateur bands only.
Frequency ranges will vary according to transceiver version; check with your dealer.
