Yamaha 2001 YZF-R6 Service Manual

22
1
3
5
7
9
2
4
8
6
24 25
2321
19 2018
15
1413
11 12
10
GEN
INFO
SPEC
ENG
CARB
ELEC
CHK
ADJ
TRBL
SHTG
16 17
COOL
CHAS
EB003000
SYMBOLS
The following symbols are not relevant to every
vehicle.
Symbols
1
to
9
indicate the subject of each
chapter.
1
General information
2
Specifications
3
Periodic checks and adjustment
4
Engine
5
Cooling system
6
Carburetor(-s)
7
Chassis
8
Electrical system
9
Troubleshooting
Symbols
10
to
17
indicate the following.
10
Serviceable with engine mounted
11
Filling fluid
12
Lubricant
13
Special tool
14
Tightening torque
15
Wear limit, clearance
16
Engine speed
17
Electrical data
Symbols
18
to
23
in the exploded diagrams indi-
cate the types of lubricants and lubrication
points.
18
Apply engine oil
19
Apply gear oil
20
Apply molybdenum disulfide oil
21
Apply wheel bearing grease
22
Apply lightweight lithium-soap base grease
23
Apply molybdenum disulfide grease
Symbols
24
to
25
in the exploded diagrams indi-
cate the following:
24
Apply locking agent (LOCTITE

)
25
Use new one
