4-25
GB
To clean the fuel filter:
1) Remove the screws holding the fuel
meter assembly. Pull the assembly
out of the tank.
2) Clean the filter (located on the end of
the suction pipe) in a suitable clean-
ing solvent. Allow the filter to dry.
3) Replace the gasket with a new one.
Reinstall the fuel meter assembly and
tighten the screws firmly.
EML24010
INSPECTING AND REPLACING
ANODE
Yamaha outboard motor is protected
from corrosion by a sacrificial anode.
Check the anode periodically. Remove the
scales from surfaces of the anode.
For the replacement of the anode, consult
a Yamaha dealer.
cC
Do not paint the anode, for this would
render it ineffective.
EML40010
CHECKING BOLTS AND NUTS
1) Check that bolts securing the cylinder
head and engine and the nut securing
the flywheel are tightened with their
specified tightening torques.
2) Check the tightening torques of other
bolts and nuts.
2
4/5
3
6A1-9-7LA0-4C 3/7/02 12:18 PM Page 160
