CDX-596
CDX-596
■
TEST MODE
(1) Turning ON the POWER while pressing the keys “PLAY/PAUSE” and “STOP” will set to the TEST mode.
(When the TEST mode is set, all indicators light for 1 second.)
A
7
Tracking gain rough ADJ
- * Data f etch cycle -
After searching the beginning, PLAY starts.
- PLA Y -
MUTE ON
TRACK search
MUTE ON
Spindle motor stop
: MUTE OFF = H → L (Q201 Collector)
"0:00" appears in the time indicator.
Tracking balance ADJ (only tray OPEN/CLOSE)
Focus balance ADJ
Focus gain ADJ
Tracking gain ADJ
* TOC READ
TRACK NO. “1” is searched.
Set to SEARCH by means of , key.
After searching the beginning, MUTE is cancelled.
- PLA Y -
Press the STOP key.
Laser OFF
Forced feed return
- STOP -
: MUTE ON = L → H
: MUTE OFF = H → L
"0:00" appears in the time indicator.
: LDON = “H” → “L” (IC1, 5 pin)
