Yamaha MT-10 SP User Manual

Description
3-2
1
2
3
4
5
6
7
8
9
10
11
12
13
EAU10421
Right view
687 5
21 3, 4
1. Tool kit (page 8-2)
2. Fuel tank cap (page 5-30)
3. ERS coupler (page 5-34)
4. Spring preload adjuster (page 5-35)
5. Coolant reservoir (page 8-14)
6. Engine oil filler cap (page 8-10)
7. Brake pedal (page 5-28)
8. Rear brake fluid reservoir (page 8-23)
BGG-9-10-E0.book 2 ページ ２０２２年１月２６日 水曜日 午前１１時３７分

Yamaha MT-10 SP Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Fuel System	Fuel injection
Transmission	6-speed
Final Drive	Chain
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/55ZR17M/C (75W)
Wheelbase	1, 405 mm
Seat Height	835 mm
Length	2, 095 mm
Width	800 mm
Minimum Ground Clearance	135 mm
Maximum Torque	111.0 Nm (11.3 kg-m) @ 9, 000 rpm
Front Brakes	Dual 320 mm hydraulic disc, ABS
Rear Brakes	220 mm hydraulic disc, ABS
Fuel Capacity	17 liters
