3 RECOMMENDED GREASES AND FLUIDS
1= Engine oil
2= Fuel tank
3= Hydraulic oil
4= Sprocket wheel
5= Idle wheel
6= Track roller
7= Support roller
8= Cooling system
9= Greaser
• Select a fuel and an oil according to the machine's operating temperature.
• The machines may run on type B bio diesel.
• Always use a Yanmar long-life cooling fluid.
IMPORTANT
Do not mix different types of oils.If you need to top up the oil with a different make or type
from the oil left in the tank, remove the remaining oil completely.
Components
Fluid
Temperatures °C
Quantity prescribed (L)
-
-20 -10 0 10 20 30
+
Thermal engine Engine oil
SAE 10W CD
3,7
+ 0,4
Oil filter
SAE 10W-30CD
SAE 15W-40CD
Travel gears
Box oil
SAE 90 (GL-4) 0,5 by reducer
Hydraulic circuit Hydraulic oil
ISO VG46
25,2
in the tank
4,8
the rest
Fuel tank Diesel
N° 2-D
38,5
–
N° 3-D
N° 3-D (S)
Cooling system
Long-life cooling fluid YANMAR POWER COOLANT B–36
3,8
radiator
0,4
expansion flask
137
