7 Mechanical Installation
28 YASKAWA TOEPC71061752B GA500 Drive Installation & Primary Operation
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
4044A
190
(7.48)
350
(13.78)
204
(8.03)
160
(6.30)
15
(0.59)
336
(13.23)
7
(0.28)
94
(3.70)
5
(0.20)
M6
6.5
(14.3)
4060A
190
(7.48)
350
(13.78)
204
(8.03)
160
(6.30)
15
(0.59)
336
(13.23)
7
(0.28)
94
(3.70)
5
(0.20)
M6
6.5
(14.3)
Table 7.14 Three-Phase 400 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
4018E
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
4023E
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
4031E
180
(7.09)
300
(11.81)
196
(7.72)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
5.5
(12.1)
4038E
180
(7.09)
300
(11.81)
196
(7.72)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
5.5
(12.1)
4044E
190
(7.48)
350
(13.78)
251
(9.88)
160
(6.30)
15
(0.59)
336
(13.23)
7
(0.28)
94
(3.70)
5
(0.20)
M6
8.0
(17.6)
4060E
190
(7.48)
350
(13.78)
251
(9.88)
160
(6.30)
15
(0.59)
336
(13.23)
7
(0.28)
94
(3.70)
5
(0.20)
M6
8.5
(18.7)
◆ Installation Position and Clearances
Install the drive as shown in Figure 7.4 for sufficient airflow to cool the drive.
A - Vertical installation
B - Horizontal installation
*1
C - Rotated installation
Figure 7.4 Installation Orientation
*1 Refer to the drive Technical Reference (SIEP C710617 52) for more information about horizontal installation.
