Yealink CP860 Quick User Guide

2
Quick User Guide—CP860 HD IP Conference Phone
Ending Calls
To end a call:
Do one of the following:
• Press the EndCall softkey.
• Press .
Holding Calls
To place a call on hold:
Press the Hold softkey during a live call.
To resume a call:
If there is only one call on hold, press the Resume
softkey.
If there is more than one call on hold:
1. Press or to select the desired call.
2. Press the Resume softkey.
Parking Calls
1. To park a live call, press the Park softkey.
2. Listen to the message which identifies the
extension the call is parked on.
3. Notify the intended recipient(s).
To pick up the parked call, the recipient dials the
extension that the call was parked on.
Transferring Calls
You can transfer a call in the following ways:
Attended Transfer (Warm Transfer)
1. Press the Tran softkey to place a call on hold.
2. Enter the number you want to transfer to, then
press , or to dial out.
3. Press the Tran softkey after second party answers.
Blind Transfer
Do one of the following:
1. Press Tran softkey to hold on a call.
2. Enter the number you want to transfer to.
3. Press the Tran softkey.
OR
1. Press the BXfer softkey during a live call.
2. Enter the extension number that you want to
transfer to.
3. Press the OK softkey.
Semi-Attended Transfer
1. Press the Tran softkey during a call.
2. Enter the number you want to transfer to, then
press , or to dial out.
3. Press the Tran softkey when you hear the
confirming ring.
Transferring Live Calls to Voicemail
1. Press the xfrVM softkey during a live call.
2. Dial the extension number, and press #.
Forwarding Calls
Placing Intercom Calls
To place an intercom call when the target phone is idle:
1. Press the Intercom softkey when the phone is idle.
2. Enter the number you wish to intercom to, and then
press the OK softkey. The called destination should
automatically answer the call in the speakerphone.
3. To end the intercom call, press the EndCall softkey.
LCR - Last Call Return
Press the LCR softkey when the phone is idle.
Placing Conference Calls
To convert a live call to a conference call:
1. Press the Conf softkey during a live call. The call is
placed on hold.
2. Enter the number of the second party, and then
press , or the Send softkey.
3. Press the Conf softkey again when the second
party answers. All parties are now joined in the
conference.
During the local conference call, you can do the
following:
• Press the Hold softkey to place the conference on
hold.
• Press the Split softkey to split the conference call
into two individual calls on hold.
Vantact recommends using call forwarding in the Virtual
Oce using the *71 command.

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
