Yealink MP54 Quick Installation Guide

1
2
x 3
x 2
100mm
74mm
148mm
99.3mm
64mm
Mounting the Screws
Yealink provides the wall mount drilling templates, which locate and
mark the position for mounting the screws (not provided) on the wall, as
shown below:
For American standard:
For others:
Attaching the Wall Mount Bracket
PC
PC
Screw position
Max:8mm
(0.315’’)
Min:6.5mm
(0.256’’)
Max:4.5mm
(0.177’’)
Screw position
Max:8mm
(0.315’’)
Min:6.5mm
(0.256’’)
Max:4.5mm
(0.177’’)
