Yealink SIP-T33P Getting Started

Recovery Mode on Yealink IP phones
15
Procedures
1. Long press (Speakerphone key) and reconnect the power adapter to trigger the recovery
mode. Do not release until the recovery mode selection screen appears on the phone LCD
screen.
Note
2. Press 2 on the phone keypad to use USB flash drive.
The IP phone will read and upgrade the firmware from the USB flash drive.
After upgrading, the IP phone will initialize successfully and get ready for use. The LCD screen
prompts “Initializing…Please wait” when upgrading successfully.
3. If the IP phone fails to upgrade, the LCD screen will indicate the failure. You need to check and make
sure:
 The file system of the USB flash drive should be FAT32.
 The USB flash drive has been successfully connected to the IP phone.
 The resource files are correctly renamed and placed on the USB flash drive.
 Repeat the recovery mode procedures to try again.
The LCD screen prompts “Update failed (-1)” when failing to upgrade:
4. Press to verify the current firmware version after upgrading successfully.
Note
…. Update failed (-1) ….
For CP920, you need to long press the specified soft key (the second from the left on the phone)
since there is no Speakerphone key.
Press 1 to use the TFTP server. For more information on recovery mode using the TFTP server,
refer to For SIP Phone Series.
Welcome
.... Initializing…Please wait ….
You need to tap Settings->Status (for VP59/SIP-T58A IP phones) or tap Menu->Settings (for
SIP-T57W IP phones) to verify the current firmware version since there is no key.
1. TFTP
2: USB

Yealink SIP-T33P Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Operating system installed	Linux
Lines quantity	4 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	4
Volume control	Buttons
Number of function keys	5
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Voice codecs	AGC, AJB, CNG, G.711a, G.711u, G.722, G.723.1, G.726, G.729, G.729A, PLC, VAD, iLBC
Security algorithms	AES, HTTPS
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
RJ-9 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	3 W
Power consumption (Power over Ethernet (PoE))	5 W
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	186 mm
Width	212 mm
Height	146 mm
