Yealink VC400 Administrator's Guide

Administrator’s Guide for Yealink Video Conferencing Systems
108
4. Configure the StarLeaf Cloud platform.
5. Click Confirm to accept the change.
To configure StarLeaf Cloud platform via the remote control:
1. Select Menu->Advanced (default password: 0000)->Video Conference Platform.
2. In the Cloud Account field, check the Enabled checkbox.
3. Select StarLeaf from the pull-down list of Platform Type.
4. Enter the 12-digit quick access code in the QCP Code field.
5. Press or to scroll to Log In, and then press .
After successful registration, the display device displays , and the LCD screen of the
video conferencing phone displays .
Note
Logging into the Zoom Cloud Platform
You can log into the Zoom Cloud platform and join the VMR.
Zoom Cloud platform parameters on the system are described below:
Parameter
Description
Configuration Method
Cloud Account
Enables or disables the Cloud feature.
Remote Control
Systems that log into the StarLeaf Cloud platform will upgrade firmware automatically once the
current firmware version is different from the one on StarLeaf Server.

Yealink VC400 Specifications

General

Optical zoom	18 x
White balance	Auto, Indoor, Outdoor
Focus adjustment	Auto
Video codecs	H.264, H.264, H.263
Supported video modes	1080p
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.711a, G.722
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
ITU-supported standards	H.323
Ethernet LAN data rates	10, 100, 1000 Mbit/s
AC input voltage	100-240 V
Power consumption (max)	30 W

Weight and Dimensions

Depth	183 mm
Width	330 mm
Height	40 mm
