York 16 SEER User Manual

898147-UUM-B-0713
4 Johnson Controls Unitary Products
MULTI-SPLITS
FIGURE 2: Multi-Split Units
18 KBTU OUTDOOR UNIT
(ONE TO TWO ZONES)
24 KBTU OUTDOOR UNIT
(TWO TO THREE ZONES)
30 KBTU OUTDOOR UNIT
(TWO TO FOUR ZONES)
42 KBTU OUTDOOR UNIT
(TWO TO FIVE ZONES)
AIR IN
AIR OUT
1
2
3
8
4
5
7
6
1. Front Panel
2. Filter
3. Guide Louver
4. Wall Pipe
5. Bind Tape
6. Connection Wire
7 Drainage Pipe
8. Remote Control
INDOOR UNIT
OUTDOOR UNIT

York 16 SEER Specifications

General

Brand	York
Model	16 SEER
Category	Air Conditioner
Language	English
