NOTE 1: HACR Type per NEC.
TABLE 9: J**DJ ELECTRICAL DATA WITHOUT POWERED CONVENIENCE OUTLET (CONTINUED)
MODEL
(TON-
NAGE)
VOLTAGE
COMPRESSORS
OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
MODEL KW STAGES AMPS
J20
(20)
208 33.6 225 3.7 20.0 0.0
None 0.0 ~ ~ 110.4 125
E18 13.5 1 37.5 110.4 125
E36 27.0 2 75.1 118.7 125
E54 40.6 2 112.6 165.9 175
E72 54.1 2 150.1 175.2 200
230 33.6 225 3.7 20.0 0.0
None 0.0 ~ ~ 110.4 125
E18 18.0 1 43.3 110.4 125
E36 36.0 2 86.6 133.3 150
E54 54.0 2 129.9 154.9 175
E72 72.0 2 173.2 198.2 225
460 17.3 114 1.9 10.0 0.0
None 0.0 ~ ~ 56.5 70
E18 18.0 1 21.7 56.5 70
E36 36.0 2 43.3 66.6 70
E54 54.0 2 65.0 77.5 90
E72 72.0 2 86.6 99.1 110
575 13.5 80 1.5 8.2 0.0
None 0.0 ~ ~ 44.6 50
E18 18.0 1 17.3 44.6 50
E36 36.0 2 34.6 53.6 60
E54 54.0 2 52.0 62.2 70
E72 72.0 2 69.3 79.5 90
J25
(25)
208 47.1 245 3.7 38.6 0.0
None 0.0 ~ ~ 159.4 200
E18 13.5 1 37.5 159.4 200
E36 27.0 2 75.1 159.4 200
E54 40.6 2 112.6 189.1 200
E72 54.1 2 150.1 198.4 225
230 47.1 245 3.7 38.6 0.0
None 0.0 ~ ~ 159.4 200
E18 18.0 1 43.3 159.4 200
E36 36.0 2 86.6 159.4 200
E54 54.0 2 129.9 178.2 200
E72 72.0 2 173.2 221.5 250
460 19.6 125 1.9 19.3 0.0
None 0.0 ~ ~ 71.0 90
E18 18.0 1 21.7 71.0 90
E36 36.0 2 43.3 78.3 90
E54 54.0 2 65.0 89.1 100
E72 72.0 2 86.6 110.7 125
575 15.8 100 1.5 15.4 0.0
None 0.0 ~ ~ 57.0 70
E18 18.0 1 17.3 57.0 70
E36 36.0 2 34.6 62.6 70
E54 54.0 2 52.0 71.2 80
E72 72.0 2 69.3 88.5 100
VOLTAGE LIMITATIONS
1
ELECTRIC HEAT CORRECTION FACTORS
POWER SUPPLY
VOLTAGE NOMINAL VOLTAGE VOLTAGE kW CAP. MULTIPLIER
MIN. MAX. 208 208 1.00
208/230-3-60 187 253 240 230 0.92
460-3-60 414 506 480 460 0.92
575-3-60 518 630 600 575 0.92
1.
Utilization Range “A” in accordance with ARI Standard 110.
