York AHP18 User Manual

255029-YTG-M-0610
8 Johnson Controls Unitary Products
* May be 0 (no breaker) or 1 (with breaker).
ELECTRICAL DATA (FOR SINGLE SOURCE POWER SUPPLY) - COPPER WIRE 208/230-1-60
Models
Heater
Models*
Heater
Amps
240V
Field Wiring
Min. Circuit Ampacity
Max. O.C.P.
1
Amps/Type
75°C Wire Size - AWG
208V 240V 208V 240V 208V 240V
AHP18B**H21
4HK*6500206 10.4 13.5 15.4 15 20 12 12
4HK*6500506 20.0 23.8 27.4 25 30 10 10
4HK*6500806 31.3 36.0 41.5 40 45 8 8
AHP24B**H21
4HK*6500206 10.4 13.0 14.9 15 15 12 12
4HK*6500506 20.0 23.4 26.9 25 30 10 10
4HK*6500806 31.3 35.6 41.0 40 45 8 8
4HK*6501006 40.0 45.1 51.9 45 60 8 6
4HK16501306 54.2 60.4 69.6 70 70 4 4
AHP30B**H21
4HK*6500506 20.0 24.2 27.8 25 30 10 10
4HK*6500806 31.3 36.4 41.9 40 45 8 8
4HK*6501006 40.0 45.8 52.8 50 60 8 6
4HK16501306 54.2 60.1 70.5 70 90 4 3
4HK165N1506 60.0 67.5 77.8 70 90 4 3
AHP36C**H21
4HK*6500506 20.0 25.8 29.5 30 30 10 10
4HK*6500806 31.3 38.0 43.6 40 45 8 8
4HK*6501006 40.0 47.5 54.5 50 60 8 6
4HK16501506 60.0 69.1 79.5 70 90 4 3
4HK16501806 73.3 83.6 96.1 90 100 3 3
AHP42C**H21
4HK*6500506 20.0 25.9 29.8 30 30 8 8
4HK*6500806 31.3 38.1 43.9 40 45 8 8
4HK*6501006 40.0 47.6 54.8 50 60 6 6
4HK16501506 60.0 69.3 79.8 70 90 4 3
4HK16501806 73.3 83.7 96.4 90 100 3 3
4HK16502006 80.0 90.9 104.8 100 110 3 2
AHP48D**H21
4HK*6500506 20.0 25.9 29.8 30 30 10 10
4HK*6500806 31.3 38.1 43.9 40 45 8 8
4HK*6501006 40.0 47.6 54.8 50 60 8 6
4HK16501506 60.0 69.3 79.8 70 90 4 3
4HK16501806 73.3 83.7 96.4 90 100 3 3
4HK16502006 80.0 90.9 104.8 100 110 3 2
AHP60D**H21
4HK*6500506 20.0 31.2 34.5 35 35 8 8
4HK*6500806 31.3 43.4 48.6 45 50 8 8
4HK*6501006 40.0 52.8 59.5 60 60 6 6
4HK16501506 60.0 74.5 84.5 90 90 3 3
4HK16501806 73.3 88.9 101.1 90 110 3 2
4HK16502006 80.0 96.2 109.5 100 125 3 1
4HK16502506 100.0 117.8 134.5 125 150 1 1/0
1. O.C.P. = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
