York DC-120 User Manual

5120410-XIM-B-0216
Johnson Controls Unitary Products 35
DC090 (26 kW) Optional Motor Side Duct Metric
ESP
(Pa)
Turns Open
0 1 2 3 4 5
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
62
– – – – – – – – – – – – 1.72 1.8 1.46 1.55 1.56 1.25
125
– – – – – – – – – – – – 1.53 1.65 1.33 1.38 1.43 1.14
199
– – – – – – – – – – – – 1.31 1.5 1.20 1.18 1.3 1.04
249
1.68 2.44 1.95 1.55 2.12 1.70 1.44 1.86 1.49 1.31 1.59 1.27 1.18 1.39 1.11 1.04 1.18 0.94
299
1.52 2.31 1.85 1.43 1.99 1.59 1.32 1.73 1.38 1.18 1.48 1.18 1.04 1.26 1.01 0.87 1.05 0.84
349
1.46 2.16 1.73 1.31 1.86 1.49 1.16 1.59 1.27 1.03 1.33 1.06 0.81 1.09 0.87 – – –
399
1.35 2.04 1.63 1.17 1.71 1.36 1.01 1.45 1.16 – – – – – – – – –
448
1.19 1.86 1.49 1.03 1.55 1.24 – – – – – – – – – – – –
498
1.03 1.68 1.34 – – – – – – – – – – – – – – –
DC120 (10 Ton) Standard Motor Side Duct Imperial
ESP
(iwg)
Turns Open
0 1 2 3 4 5
CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP
0.35
4820 2675 2.87 4582 2362 2.53 4319 2080 2.23 4086 1842 1.98 3863 1648 1.77 3590 1430 1.53
0.6
4522 2496 2.68 4307 2215 2.38 4025 1941 2.08 3713 1678 1.80 3464 1499 1.61 3149 1291 1.38
0.8
4223 2332 2.50 3973 2062 2.21 3656 1783 1.91 3363 1550 1.66 3026 1350 1.45 - - -
1.0
3913 2174 2.33 3679 1923 2.06 3262 1619 1.74 2721 1330 1.43 - - - - - -
1.2
3521 1978 2.12 3104 1693 1.82 - - - - - - - - - - - -
1.4
2790 1660 1.78 - - - - - - - - - - - - - - -
DC120 (35 kW) Standard Motor Side Duct Metric
ESP
(Pa)
Turns Open
0 1 2 3 4 5
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
87
2.27 2.68 2.14 2.16 2.36 1.89 2.04 2.08 1.66 1.93 1.84 1.47 1.82 1.65 1.32 1.69 1.43 1.14
149
2.13 2.50 2.00 2.03 2.22 1.77 1.90 1.94 1.55 1.75 1.68 1.34 1.63 1.50 1.20 1.49 1.29 1.03
199
1.99 2.33 1.87 1.88 2.06 1.65 1.73 1.78 1.43 1.59 1.55 1.24 1.43 1.35 1.08 - - -
249
1.85 2.17 1.74 1.74 1.92 1.54 1.54 1.62 1.30 1.28 1.33 1.06 - - - - - -
299
1.66 1.98 1.58 1.46 1.69 1.35 - - - - - - - - - - - -
349
1.32 1.66 1.33 - - - - - - - - - - - - - - -
