York DC SERIES User Manual

5120410-XIM-B-0216
Johnson Controls Unitary Products 15
Figure 12: DC090-150 Unit Left Duct Opening
Table 10: ZF Side Duct Dimensions Imperial
Unit Model Number
Dimension (in.)
ABCD
090 27 3/4 12 1/16 27 1/2 16
120 28 1/4 18 1/16 28 1/4 18 1/4
150 28 1/4 18 1/16 28 1/4 18 1/4
Table 11: ZF Side Duct Dimensions Metric
Unit Model Number
Dimension (mm)
ABCD
090 705 306 698 406
120 718 459 718 464
150 718 459 718 464
4-5/16
30-3/8
(772)
(110)
5 0 - 1 / 2
( 1 2 8 5 )
3 0
( 7 6 0 )
2 0
( 5 1 0 )
8 0 - 5 / 8
( 2 0 5 0 )
6
( 1 5 0 )
2 T Y P .
( 5 0 )
I N S U L A T E D D E C K U N D E R
C O M P R E S S O R S E C T I O N
I N S U L A T E D D E C K U N D E R
C O N D E N S E R S E C T I
O N
F R O N T
R I G H T
S U P P L Y
R E T U R N
2 0
( 5 1 0 )
N O T E :
( X X X ) I N D I C A T E S
D I M E N S I O N S I N
M I L L I M E T E R S
1 4
( 3 5 5 )
8
( 2 0 5 )
O R
