York E4FD018 User Manual

036-21030-003 Rev. B (0203)
2 Unitary Products Group
PHYSICAL AND ELECTRICAL DATA - 1 Phase
MODEL
E4FD018 E4FD024 E4FD030 E4FD036 E4FD042 E4FD048 E4FD060
Unit Supply Voltage 208/230-1-60
Normal Voltage Range
1
187 to 252
Minimum Circuit Ampacity 11.3 15.4 19.4 23.2 27.2 33.1 39.2
Max. Overcurrent Device Amps
2
20 25 30 35 40 50 60
Compressor Type
3
Recip Recip Recip Recip Recip
Scroll
C
Scroll
B
Compressor Amps
Rated Load 6.7 11.6 14.8 17.3 20.5 25.2 29.9
Locked Rotor 48 60 73 86 120 131 165
Crankcase Heater Yes Yes Yes Yes Yes No No
Fan Motor Amps Rated Load 0.9 0.9 0.9 1.6 1.5 1.6 1.8
Fan Diameter Inches 18 18 18 18 24 24 24
Fan Motor
Rated HP 1/8 1/8 1/8 1/4 1/4 1/4 1/3
Nominal RPM 1075 1075 1075 1100 860 860 1100
Nominal CFM 2050 2050 2050 2200 3200 3200 4100
Coil
Face Area Sq. Ft. 14.1 14.1 14.1 14.1 20 20 24
Rows Deep 1111111
Fin / Inches 13 13 13 16 13 16 16
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Unit Charge (Lbs. - Oz.)
4
4 - 11 4 - 12 5 - 3 5 - 11 7 - 6 7 - 6 9 - 5
Charge Per Foot, Oz. 0.680.680.680.680.700.700.70
Operating Weight Lbs. 158 162 168 173 225 210 246
PHYSICAL AND ELECTRICAL DATA - 3 Phase
MODEL
E4FD036 E4FD048 E4FD060 E4FD036 E4FD048 E4FD060
25 46
Unit Supply Voltage 208/230 - 3 - 60 460 - 3 - 60
Normal Voltage Range
1
187 TO 253 432 TO 504
Minimum Circuit Ampacity 15.2 20.1 25.0 8.0 9.0 11.4
Max. Overcurrent Device Amps
2
25 30 40 15 15 15
Compressor Type
3
Recip
Scroll
C
Scroll
B
Recip
Scroll
C
Scroll
B
Compressor Amps
Rated Load 10.9 14.8 18.5 5.8 6.5 8.3
Locked Rotor 78 91 125 40 46 67
Crankcase Heater Yes No No Yes No No
Fan Motor Amps Rated Load 1.6 1.6 1.8 0.8 0,8 1.0
Fan Diameter Inches 18 24 24 18 24 24
Fan Motor
Rated HP 1/4 1/4 1/3 1/4 1/4 1/3
Nominal RPM 1100 860 1100 1075 860 1100
Nominal CFM 2200 3200 4100 2200 3200 4100
Coil
Face Area Sq. Ft. 14.1 20 24 14.1 20 24
Rows Deep 111111
Fin / Inches 16 16 16 16 16 16
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 3/4 7/8 7/8 3/4 7/8 7/8
Unit Charge (Lbs. - Oz.)
4
5 - 11 7 - 6 9 - 5 5 - 11 7 - 6 9 - 5
Charge Per Foot, Oz. 0.68 0.70 0.70 0.68 0.70 0.70
Operating Weight Lbs. 173 210 246 173 210 246
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker.
3. All scrolls listed with a superscript “B” are Bristol scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than
15 feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.

York E4FD018 Specifications

General

Brand	York
Model	E4FD018
Category	Heat Pump
Language	English
