York LX series Technical Guide

5581700-YTG-F-1021
10 Johnson Controls Ducted Systems
— = not applicable.
YCE48B21S MVC20DN21 24.5 CF/CM48D 1450 48.0 35.0 15.50 12.75
YCE48B21S MVC20DN21 24.5 CF/CM60D 1475 48.0 35.5 15.75 12.75
YCE48B21S MVC20DN21 24.5 CF/CM64D 1375 48.0 34.0 16.00 13.00
YCE60B21S AE60CX21 21.0 — 1625 56.0 40.0 14.25 12.00
YCE60B21S AP60DX22 24.5 — 1525 54.5 38.0 14.00 11.75
YCE60B21S AP60DX23 24.5 — 1525 54.5 38.0 14.00 11.75
YCE60B21S AVC60CX21 21.0 — 1750 56.5 41.5 14.00 12.00
YCE60B21S AVC60DX21 24.5 — 1650 57.5 41.0 14.75 12.25
YCE60B21S ME16CN21 21.0 CF/CM60C 1625 56.0 40.0 14.50 12.25
YCE60B21S ME20DN21 24.5 CF/CM60D 1650 56.5 40.0 14.50 12.25
YCE60B21S ME20DN21 24.5 CF/CM64D 1625 57.5 40.5 14.75 12.25
YCE60B21S MVC16CN21 21.0 CF/CM60C 1650 57.0 40.5 15.50 12.75
YCE60B21S MVC20DN21 24.5 CF/CM60D 1700 56.0 40.0 14.50 12.00
YCE60B21S MVC20DN21 24.5 CF/CM64D 1700 57.0 40.5 14.75 12.25
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated airflow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in
watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. Refer to the Price Pages for specific model number.
SYSTEM CAPACITY - Upflow, Downflow and Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL
CFM RANGE
(MINIMUM–
MAXIMUM)
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
YCE18B22S CF/CM/CU18A 14.5 450 - 750 600 17.1 12.3 14.20 12.00
YCE18B22S CF/CM/CU18B 17.5 450 - 750 600 17.1 13.8 14.00 12.00
YCE18B22S CF/CM/CU24A 14.5 450 - 750 600 17.5 14.0 14.00 12.00
YCE18B22S CF/CM/CU24B 17.5 450 - 750 600 17.5 14.0 14.00 12.00
YCE18B22S CF/CM/CU30A 14.5 450 - 750 600 17.7 14.1 14.00 12.25
YCE18B22S CF/CM/CU30B 17.5 450 - 750 600 17.7 14.1 14.00 12.25
YCE18B22S CF/CM/CU36B 17.5 450 - 750 600 17.8 14.0 14.00 12.25
YCE18B22S CF/CM/CU36C 21.0 450 - 750 600 17.8 14.0 14.00 12.25
YCE18B22S CF/CM24C 21.0 450 - 750 600 17.5 14.0 14.00 12.00
YCE18B22S CF/CM30C 21.0 450 - 750 600 17.7 14.1 14.00 12.25
YCE18B22S CF/CM36D 24.5 450 - 750 600 17.8 14.0 14.00 12.25
YCE18B22S XAF/XAUA24B 14.5 450 - 750 600 17.5 13.1 14.00 12.00
YCE18B22S XAFB24B 17.5 450 - 750 600 17.5 13.1 14.00 12.00
YCE18B22S XAHA24B 14.5 450 - 750 600 17.5 13.1 14.00 12.00
YCE18B22S XAHB24B 17.5 450 - 750 600 17.5 13.1 14.00 12.00
YCE24B22S CF/CM/CU24A 14.5 600 - 1000 800 23.8 16.8 14.00 12.00
YCE24B22S CF/CM/CU24B 17.5 600 - 1000 800 23.8 18.6 14.00 12.00
YCE24B22S CF/CM/CU30A 14.5 600 - 1000 800 23.8 18.6 14.00 12.00
YCE24B22S CF/CM/CU30B 17.5 600 - 1000 800 23.8 18.6 14.00 12.00
YCE24B22S CF/CM/CU36B 17.5 600 - 1000 800 23.8 18.6 14.00 12.00
YCE24B22S CF/CM/CU36C 21.0 600 - 1000 800 23.8 18.6 14.00 12.00
YCE24B22S CF/CM/CU42C 21.0 600 - 1000 800 24.0 18.5 14.25 12.25
YCE24B22S CF/CM24C 21.0 600 - 1000 800 23.8 18.6 14.00 12.00
YCE24B22S CF/CM30C 21.0 600 - 1000 800 23.8 18.6 14.00 12.00
YCE24B22S CF/CM36D 24.5 600 - 1000 800 23.8 18.6 14.00 12.00
YCE24B22S CF/CM42D 24.5 600 - 1000 800 24.0 18.5 14.25 12.25
YCE24B22S XAF/XAUA24B 14.5 600 - 1000 800 23.8 17.8 14.00 12.00
SYSTEM CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
