York LX series Technical Guide

5581700-YTG-F-1021
12 Johnson Controls Ducted Systems
PSC furnaces use coil only ratings.
YCE48B21S CF/CM/CU48C 21.0 1400 - 1800 1600 47.5 34.2 14.00 11.75
YCE48B21S CF/CM/CU48D 24.5 1400 - 1800 1600 47.5 34.2 14.00 11.75
YCE48B21S CF/CM60C 21.0 1400 - 1800 1600 48.0 34.4 14.00 11.75
YCE48B21S CF/CM60D 24.5 1400 - 1800 1600 48.0 34.4 14.00 11.75
YCE48B21S CF/CM64D 24.5 1400 - 1800 1600 48.0 36.0 14.50 12.25
YCE48B21S XAF/XAUC48F 21.0 1400 - 1800 1525 47.0 32.8 14.00 11.75
YCE48B21S XAF/XAUC60G 21.0 1400 - 1800 1600 48.0 34.4 14.00 11.75
YCE48B21S XAF/XAUD60G 24.5 1400 - 1800 1600 48.0 34.4 14.00 11.75
YCE48B21S XAFD48F 24.5 1400 - 1800 1600 47.0 33.6 14.00 11.75
YCE48B21S XAHC48F 21.0 1400 - 1800 1525 47.0 32.8 14.00 11.75
YCE48B21S XAHC60G 21.0 1400 - 1800 1600 48.0 34.4 14.00 11.75
YCE48B21S XAHD48F 24.5 1400 - 1800 1600 47.0 33.6 14.00 11.75
YCE48B21S XAHD60G 21.0 1400 - 1800 1600 48.0 34.4 14.00 11.75
YCE60B21S CF/CM/CU60C 21.0 1535 - 1935 1735 56.0 41.0 14.00 11.75
YCE60B21S CF/CM/CU60D 24.5 1535 - 1935 1725 56.0 41.0 14.00 11.75
YCE60B21S CF/CM64D 24.5 1535 - 1935 1775 57.0 42.0 14.00 11.75
YCE60B21S XAF/XAUC60G 21.0 1520 - 1920 1725 55.5 40.0 14.00 11.75
YCE60B21S XAF/XAUD60G 24.5 1520 - 1920 1725 55.5 40.0 14.00 11.75
YCE60B21S XAF/XAUD60H 24.5 1520 - 1920 1725 56.0 41.0 14.00 11.75
YCE60B21S XAFC60H 21.0 1520 - 1920 1725 56.0 41.0 14.00 11.75
YCE60B21S XAHC60G 21.0 1520 - 1920 1725 55.5 40.0 14.00 11.75
YCE60B21S XAHC60H 21.0 1520 - 1920 1725 56.0 41.0 14.00 11.75
YCE60B21S XAHD60G 21.0 1520 - 1920 1600 55.0 39.0 14.00 11.75
YCE60B21S XAHD60H 24.5 1520 - 1920 1700 56.0 40.5 14.00 11.75
For rated condition information, see the COOLING CAPACITY - With Air Handler Coils table footnotes.
1. Requires a Blower Time Delay unless a standard furnace is equipped with one.
SYSTEM CAPACITY - Upflow, Downflow and Horizontal Furnaces and Coils (Coil Only Ratings) (Continued)
UNIT MODEL
COIL
CFM RANGE
(MINIMUM–
MAXIMUM)
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
YCE18B22S TL8E060A12UH11 14.5 CF/CM/CU18A 600 17.7 14.3 15.75 13.00
YCE18B22S TL8E060A12UH11 14.5 CF/CM/CU18B 650 17.7 14.6 16.00 13.25
YCE18B22S TL8E060A12UH11 14.5 CF/CM/CU24A 600 17.8 14.2 16.00 13.25
YCE18B22S TL8E060A12UH11 14.5 CF/CM/CU24B 700 17.8 15.4 16.00 13.25
YCE18B22S TL8E060A12UH11 14.5 CF/CM/CU30A 600 17.8 14.2 16.00 13.25
YCE18B22S TL8E060A12UH11 14.5 CF/CM/CU30B 700 17.9 15.1 16.00 13.25
YCE18B22S TL8E060A12UH11 14.5 CF/CM/CU36B 700 18.0 15.0 16.00 13.25
YCE18B22S TL8E060A12UH11 14.5 CF/CM36A 625 18.0 14.8 16.00 13.25
YCE18B22S TL8E060A12UH11 14.5 XAF/XAUA24B 600 17.8 13.2 16.00 13.00
YCE18B22S TL8E060A12UH11 17.5 XAFB24B 675 17.8 13.9 16.00 13.00
YCE18B22S TL8E060A12UH11 14.5 XAHA24B 600 17.8 13.2 16.00 13.00
YCE18B22S TL8E060A12UH11 17.5 XAHB24B 625 17.8 13.4 16.00 13.00
YCE18B22S TL9E060B12UH11 17.5 CF/CM/CU18B 650 17.6 14.6 15.75 13.00
YCE18B22S TL9E060B12UH11 17.5 CF/CM/CU24B 650 17.8 14.7 16.00 13.25
YCE18B22S TL9E060B12UH11 17.5 CF/CM/CU30B 675 17.9 14.8 16.00 13.25
YCE18B22S TL9E060B12UH11 17.5 CF/CM/CU36B 650 18.0 14.6 16.00 13.25
YCE18B22S TL9E060B12UH11 17.5 CF/CM/CU36C 700 18.0 15.0 16.00 13.25
YCE18B22S TL9E060B12UH11 17.5 CF/CM24C 650 17.8 14.7 16.00 13.25
YCE18B22S TL9E060B12UH11 17.5 CF/CM30C 700 17.9 15.1 16.00 13.25
YCE18B22S TL9E060B12UH11 17.5 XAFB24B 625 17.8 13.4 16.00 13.00
