5581700-YTG-F-1021
Johnson Controls Ducted Systems 187
PERFORMANCE DATA - 5 TON
CONDENSER-ONLY DATA (OUTDOOR UNIT)
MODEL
SATURATED SUCTION
AT COMPRESSOR
Outdoor Ambient Temperature
55°F 65°F 75°F 85°F 95°F 105°F 115°F 125°F
T (°F) P (PSIG) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
YCE60B21S
35 107 61.4 2.72 58.5 2.99 55.5 3.32 52.5 3.70 49.3 4.16 46.0 4.70 42.3 5.30 38.4 6.00
40 118 67.5 2.73 64.3 3.00 61.1 3.33 57.8 3.71 54.4 4.17 50.7 4.70 46.9 5.31 42.7 6.00
45 130 73.9 2.74 70.5 3.01 67.1 3.34 63.5 3.72 59.8 4.17 55.8 4.71 51.7 5.32 47.2 5.99
50 142 80.8 2.75 77.0 3.03 73.3 3.35 69.5 3.73 65.6 4.17 61.3 4.72 56.8 5.33 52.1 5.99
55 156 88.2 2.76 84.1 3.04 80.0 3.37 75.8 3.76 71.6 4.19 67.1 4.73 62.3 5.34 57.3 5.99
Notes:
1. For outdoor unit (condenser) performance only. Data does not include the effects of air handler power or heat.
2. Performance based on 15°F subcooling and 15°F superheat at the outdoor unit base valves.
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
3. Maximum recommended condensing temperature is 140°F.
COOLING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. YCE60B21S
INDOOR COIL MODEL NO. CF60CXA1
AIR TEMPERATURE
ENTERING
OUTDOOR UNIT (°F)
ID CFM 1535 1735 1935
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55
T.C. 55.3 58.7 59.6 63.7 66.8 57.5 59.6 60.2 64.3 67.1 59.7 60.5 60.7 65.0 67.5
S.C. 55.3 49.6 44.3 43.0 33.6 57.5 52.4 46.2 44.3 34.5 59.7 55.2 48.1 45.7 35.4
kW 3.10 3.14 3.13 3.15 3.17 3.19 3.22 3.21 3.24 3.25 3.27 3.30 3.29 3.32 3.33
65
T.C. 54.1 57.2 57.2 62.0 65.7 56.1 58.2 58.0 62.9 66.4 58.0 59.1 58.9 63.8 67.1
S.C. 54.1 49.2 42.6 41.9 33.0 56.1 52.1 44.9 43.7 34.1 58.0 54.9 47.2 45.5 35.1
kW 3.43 3.46 3.45 3.47 3.48 3.51 3.54 3.53 3.55 3.56 3.59 3.62 3.61 3.63 3.64
75
T.C. 52.9 55.6 54.7 60.3 64.7 54.6 56.7 55.9 61.5 65.7 56.4 57.8 57.1 62.6 66.8
S.C. 52.9 48.9 40.9 40.9 32.5 54.6 51.7 43.6 43.2 33.7 56.4 54.6 46.3 45.4 34.8
kW 3.76 3.78 3.77 3.78 3.78 3.84 3.86 3.85 3.86 3.86 3.91 3.93 3.92 3.94 3.94
85
T.C. 50.4 53.2 52.1 57.9 62.4 52.1 54.2 53.4 58.7 63.3 53.7 55.1 54.7 59.6 64.1
S.C. 50.4 47.4 39.6 39.9 31.5 52.1 50.2 42.3 42.1 32.6 53.7 52.9 45.0 44.2 33.8
kW 4.22 4.25 4.25 4.24 4.23 4.30 4.32 4.31 4.31 4.30 4.37 4.39 4.38 4.39 4.38
95
T.C. 47.9 50.8 49.6 55.4 60.2 49.5 51.6 50.9 56.0 60.8 51.1 52.5 52.3 56.6 61.4
S.C. 47.9 46.0 38.3 38.9 30.5 49.5 48.6 41.0 41.0 31.6 51.1 51.2 43.7 43.1 32.7
kW 4.69 4.71 4.72 4.70 4.67 4.75 4.78 4.78 4.77 4.75 4.82 4.84 4.84 4.83 4.82
105
T.C. 46.0 47.7 46.1 52.4 57.0 47.5 48.6 47.5 53.0 57.4 49.0 49.6 48.8 53.6 57.8
S.C. 46.0 44.5 36.4 37.6 29.1 47.5 46.9 39.0 39.7 30.2 49.0 49.3 41.7 41.8 31.4
kW 5.49 5.51 5.51 5.47 5.41 5.52 5.56 5.57 5.53 5.48 5.56 5.61 5.63 5.58 5.56
115
T.C. 44.1 44.7 42.8 49.5 53.8 45.5 45.7 44.1 50.1 54.0 46.9 46.7 45.4 50.7 54.2
S.C. 44.1 43.0 34.6 36.3 27.7 45.5 45.3 37.1 38.4 28.9 46.9 46.7 39.7 40.5 30.0
kW 6.26 6.29 6.28 6.22 6.13 6.27 6.32 6.34 6.26 6.20 6.28 6.36 6.39 6.31 6.28
125
T.C. 42.3 41.8 39.4 46.5 50.7 43.6 42.8 40.7 47.2 50.7 44.9 43.9 42.0 47.8 50.7
S.C. 42.3 41.6 32.7 35.0 26.4 43.6 42.8 35.2 37.1 27.5 44.9 43.9 37.8 39.3 28.7
kW 7.03 7.07 7.05 6.96 6.84 7.02 7.08 7.10 7.00 6.92 7.00 7.10 7.15 7.04 7.00
ALL CAPACITIES INCLUDE INDOOR FAN HEAT. kW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.
