Physical Data
ZF078-150 Physical Data
Component
Models
ZF078 ZF090 ZF102 ZF120 ZF150
Nominal Tonnage 6.5 7.5 8.5 10 12.5
AHRI COOLING PERFORMANCE
Gross Capacity @ AHRI A point (Mbh) 81000 86500 104000 126000 156000
AHRI net capacity (Mbh) 78000 84000 101000 118000 149500
EER 11.2 11.2
1
/11.0
2
11.2
1
/11.0
2
11.2
1
/11.0
2
11.0
1
/10.8
2
IEER with Constant Volume 12.9
1
/12.7
2
- 12.9
1
/12.7
2
--
IEER with Intellispeed 13.9
1
/13.7
2
13.1 14.0
1
/13.8
2
14.4
1
/14.2
2
12.8
1
/12.6
2
IEER with VAV 13.4
1
/13.2
2
12.9
1
/12.7
2
13.1
1
/12.9
2
13.2
1
/13.0
2
12.6
1
/12.4
2
CFM 2500 2500 3400 4000 4050
System power (KW) 6.95 7.87 8.90 10.70 13.40
Refrigerant type R-410A R-410A R-410A R-410A R-410A
Refrigerant charge (lb-oz)
System 1 4-8 4-10 5-12 8-4 7-10
System 2 4-8 4-8 5-12 7-2 7-4
AHRI HEATING PERFORMANCE
Heating model N12 N18 N12 N18 N12 N18 N18 N24 N18 N24
Heat input (K Btu) 120 180 120 180 120 180 180 240 180 240
Heat output (K Btu) 96 144 96 144 96 144 144 192 144 192
AFUE % ----------
Steady state efficiency (%) 80808080808080808080
No. burners 4646466868
No. stages 2
3
2
3
2
3
2
3
2
3
2
3
2
3
2
3
2
3
2
3
Temperature Rise Range (ºF) 20-50 35-65 15-45 30-60 10-40 25-55 20-50 35-65 10-40 25-55
Gas Limit Setting (ºF) 165 165 165 165 215 195 195 150 195 150
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4
DIMENSIONS (inches)
Length 89 89 89 89 119-1/2
Width 5959595959
Height 42 42 50-3/4 50-3/4 50-3/4
OPERATING WT. (lbs.) 860 880 1007 1060 1253
COMPRESSORS
4
Type Recip Scroll Recip Recip Scroll
Quantity 2 2 2 2 2
Unit Capacity Steps (%) 50 / 100 50 / 100 50 / 100 50 / 100 50 / 100
CONDENSER COIL DATA
Face area (Sq. Ft.) 18.5 23.8 29.0 29.0 29
Rows 11111
Fins per inch 23 23 23 23 23
Tube diameter (in.)/mm .71/18 .71/18 .71/18 1/25 1/25
Circuitry Type
2-pass
Microchannel
2-pass
Microchannel
2-pass
Microchannel
2-pass
Microchannel
2-pass
Microchannel
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 10.6 10.6 13.2 13.2 13.2
Rows 33344
Fins per inch 15 15 15 15 15
Tube diameter 0.375 0.375 0.375 0.375 0.375
