036-21020-003 Rev. C (0203)
6 Unitary Products Group
* Requires a 2FD Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
H4DH042S06
1225
1575
17 G1FA048S17 1400 41.0 30.8 12.15 - 10.70
21,24 G1FA048S21 1400 41.5 31.1 12.30 - 10.80
21,24 G1FA060S21,24 1400 42.5 31.9 12.45 - 11.10
- G1HD048 1400 41.0 30.8 12.25 - 10.75
21 G1NA048S21D 1400 40.5 30.4 12.15 - 10.70
17 G1UA048S17 1400 41.0 30.8 12.15 - 10.70
21,24 G1UA048S21 1400 41.5 31.1 12.30 - 10.80
21,24 G1UA060S21,24 1400 42.5 31.9 12.45 - 11.10
21 G2FD042(S,H)21 1400 40.5 30.4 12.00 - 10.60
17 G2FD046(S,H)17 1400 41.0 30.8 12.10 - 10.70
21,24 G2FD048(S,H)21,24 1400 42.0 31.5 12.35 - 10.90
24 G2FD060(S,H)24 1400 42.5 31.9 12.45 - 11.10
H4DH048S06
1400
1800
17 G1FA048S17 1600 48.0 36.0 12.20* - 11.00
21,24 G1FA048S21 1600 48.0 36.0 12.20* - 11.00
21,24 G1FA060S21,24 1600 49.5 37.1 12.50* 13.00* 11.35
- G1HD048 1600 49.0 36.8 12.00 - 11.10
- G1HD060 1600 49.5 37.1 12.20* - 11.35
21 G1NA048S21D 1600 47.0 35.3 12.00 - 10.85
17 G1UA048S17 1600 48.0 36.0 12.20* - 11.00
21,24 G1UA048S21 1600 48.0 36.0 12.20* - 11.00
21,24 G1UA060S21,24 1600 49.5 37.1 12.50* 13.00* 11.35
17 G2FD046(S,H)17 1500 47.0 35.3 12.00 - 10.75
21,24 G2FD048(S,H)21,24 1600 48.5 36.4 12.35* - 11.15
24 G2FD060(S,H)24 1600 50.0 37.5 12.50* 13.00* 11.45
H4DH060S06
1575
2025
21,24 G1FA060S21,24 1800 58.5 43.9 12.00 - 11.05
- G1HD060 2000 59.0 44.3 12.00 - 11.10
21,24 G1UA060S21,24 1800 58.5 43.9 12.00 - 11.05
24 G2FD060(S,H)24 1800 58.5 43.9 12.00 12.50 11.05
24 G2FD061H24 2000 60.0 45.0 12.00 12.50 11.25
1. TXV = Use 1TV700 Series Kit.
COOLING CAPACITY - Upflow, Downflow, & Horizontal Furnaces and Coils
*
(Continued)
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(MIN.-MAX.)
W
RATED
CFM
NET MBH
SEER
W/O TXV
SEER
+ TXV
1
EER
TOTAL SENS.
To Next Page
