York STELLAR PLUS H4DH018 THRU 060 User Manual

036-21020-003 Rev. C (0203)
8 Unitary Products Group
For Notes see Page 8.
H4DH036S06
P1DUB16V G1FA036S17 17 1220 35.8 26.5 13.00 - 11.80
P1DUB16V G1FA048S17 17 1220 38.0 28.1 13.50 - 12.40
P1DUB16V G1HD036 - 1220 35.8 26.5 13.00 - 11.65
P1DUB16V G1HD048 - 1220 38.5 28.5 13.50 - 11.85
P1DUB16V G1UA036S17 17 1220 35.8 26.5 13.00 - 11.80
P1DUB16V G1UA048S17 17 1220 38.0 28.1 13.50 - 12.40
P1DUB16V G2FD036(S,H)17 17 1220 36.4 26.9 13.00 - 12.00
P1DUB16V G2FD046(S,H)17 17 1220 36.8 27.2 13.00 - 12.00
P1DUC20V G1FA036S21 21 1220 35.8 26.5 13.00 - 11.80
P1DUC20V G1FA048S21 21 1200 38.0 28.1 14.00 - 12.65
P1DUC20V G1HD036 - 1200 36.0 26.6 13.50 - 12.15
P1DUC20V G1HD048 - 1200 39.0 28.9 14.00 - 12.30
P1DUC20V G1UA036S21 21 1220 35.8 26.5 13.00 - 11.80
P1DUC20V G1UA048S21 21 1200 38.0 28.1 14.00 - 12.65
P1DUC20V G2FD036(S,H)21 21 1200 36.6 27.1 13.50 - 12.50
P1DUC20V G2FD042(S,H)21 21 1200 36.8 27.2 13.40 - 12.10
P1DUC20V G2FD048(S,H)21 21 1200 38.5 28.5 14.00 - 12.70
P1XDB12V G2FD036(S,H)17 17 1250 36.0 26.6 12.50 - 11.55
P1XUB12V G1FA036S17 17 1220 35.4 26.2 12.40 - 11.35
P1XUB12V G1FA048S17 17 1230 38.0 28.1 13.50 - 12.45
P1XUB12V G1UA036S17 17 1220 35.4 26.2 12.40 - 11.35
P1XUB12V G1UA048S17 17 1230 38.0 28.1 13.50 - 12.45
P1XUB12V G2FD036(S,H)17 17 1200 36.0 26.6 12.60 - 11.55
P1XUB12V G2FD046(S,H)17 17 1230 36.8 27.2 13.00 - 12.00
P1XUC20V G1FA036S21 21 1200 35.8 26.5 13.00 - 11.75
P1XUC20V G1FA048S21 21 1200 38.0 28.1 13.90 - 12.60
P1XUC20V G1UA036S21 21 1200 35.8 26.5 13.00 - 11.75
P1XUC20V G1UA048S21 21 1200 38.0 28.1 13.90 - 12.60
P1XUC20V G2FD036(S,H)21 21 1200 36.6 27.1 13.50 - 12.50
P1XUC20V G2FD042(S,H)21 21 1200 37.0 27.4 13.50 - 12.45
P1XUC20V G2FD048(S,H)21 21 1200 38.5 28.5 13.90 - 12.65
H4DH042S06
P1DUB16V G1FA048S17 17 1400 41.0 30.8 12.50 - 10.95
P1DUB16V G1HD048 - 1425 41.5 31.1 13.00 - 11.45
P1DUB16V G1UA048S17 17 1400 41.0 30.8 12.50 - 10.95
P1DUB16V G2FD046(S,H)17 17 1400 41.5 31.1 12.90 - 11.20
P1DUC20V G1FA048S21 21 1420 42.5 31.9 13.00 - 11.60
P1DUC20V G1FA060S21 21 1460 43.0 32.3 13.00 - 11.55
P1DUC20V G1HD048 - 1400 41.5 31.1 12.75 - 11.15
P1DUC20V G1UA048S21 21 1420 42.5 31.9 13.00 - 11.60
P1DUC20V G1UA060S21 21 1460 43.0 32.3 13.00 - 11.55
P1DUC20V G2FD042(S,H)21 21 1460 43.0 32.3 13.00 - 11.55
P1DUC20V G2FD048(S,H)21 21 1420 42.5 31.9 13.00 - 11.70
P1XDD20V G2FD048(S,H)24 24 1365 42.0 31.5 13.00 - 11.40
P1XUC16V G1FA048S21 21 1425 42.0 31.5 13.00 - 11.50
P1XUC16V G1FA060S21 21 1425 43.0 32.3 13.00 - 11.80
P1XUC16V G1UA048S21 21 1425 42.0 31.5 13.00 - 11.50
P1XUC16V G1UA060S21 21 1425 43.0 32.3 13.00 - 11.80
P1XUC16V G2FD042(S,H)21 21 1425 41.0 30.8 12.50 - 11.30
P1XUC16V G2FD048(S,H)21 21 1425 42.5 31.9 13.00 - 11.60
P1XUC20V G1FA048S21 21 1420 42.5 31.9 13.00 - 11.60
P1XUC20V G1FA060S21 21 1410 43.0 32.3 13.10 - 11.65
P1XUC20V G1UA048S21 21 1420 42.5 31.9 13.00 - 11.60
P1XUC20V G1UA060S21 21 1410 43.0 32.3 13.10 - 11.65
P1XUC20V G2FD042(S,H)21 21 1410 41.0 30.8 12.40 - 10.95
P1XUC20V G2FD048(S,H)21 21 1420 42.5 31.9 13.00 - 11.70
For Notes see Page 8.
COOLING CAPACITY - With Variable Speed Furnaces (Continued)
UNIT MODEL
VARIABLE SPEED
FURNACE MODEL
COIL MODEL
1
W
COOLING
RATED
CFM
NET MBH
SEER
W/O TXV
SEER
+ TXV
2
EER
TOTAL SENS.

York STELLAR PLUS H4DH018 THRU 060 Specifications

General

Brand	York
Model	STELLAR PLUS H4DH018 THRU 060
Category	Air Conditioner
Language	English
