ELECTRICAL DATA
Installation
TABLE 2 – SINGLE-POINT POWER SUPPLY
See Notes and Legend on page 19
It is possible that multiple sources of power can be supplying the unit power panel. To prevent
serious injury or death, the technician should verify that NO LETHAL VOLT AG ES are
present inside the panel AFTER disconnecting power, PRIOR to working on equipment.
The unit evaporator heater uses 120VAC. Disconnecting 120VAC power from the unit, at
or below freezing temperatures, can result in damage to the evaporator and unit as a result
of the chilled liquid freezing.
SINGLE-POINT POWER SUPPLY CONNECTIONS – YCAL0043E_ - YCAL0253E_
(One Field Provided Power Supply to the chiller. Field connections to Factory Provided Power Terminal Block (standard), Non-Fused Discon-
nect Switch (optional) or Circuit Breaker (optional).)
MODEL
YCAL
VOLT HZ
SINGLE POINT FIELD SUPPLIED WIRING
MCA
1
MIN N/F
DISC SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
FACTORY SUPPLIED OPTIONAL
MIN
3
MAX
4
MIN MAX
SINGLE
POINT
DISCONNECT BREAKER
0043
380/415 50 35 60 40 45 40 45 # 10 - # 1 # 14 - 2 # 14 - 2
0057
380/415 50 46 60 50 60 50 60 # 10 - # 1 # 14 - 2 # 14 - 2
0073
380/415 50 53 60 60 70 60 70 # 10 - # 1 # 14 - 2 # 14 - 2
0087
380/415 50 62 100 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0
0107
380/415 50 73 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0
0117
380/415 50 87 100 100 100 100 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0
0133
380/415 50 94 150 100 110 100 110 # 10 - # 1 # 2 - 4/0 # 14 - 1/0
0147
380/415 50 101 150 110 110 110 110 # 10 - # 1 # 2 - 4/0 # 2 - 4/0
0157
380/415 50 110 150 125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0
0173
380/415 50 118 150 125 125 125 125 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0
0197
380/415 50 131 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0
0217
380/415 50 141 200 150 150 150 150 # 10 - 3/0 # 6 - 350 # 2 - 4/0
0237
380/415 50 154 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 4 - 300
0253
380/415 50 166 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 4 - 300
