Zebra RW SERIES User Manual

72
RW Series User Guide Appendices
Appendix A
Interface Cables
RS232 Download Cable
Part Number BL17205-1; RW Mod Plug to 9-Pin DB PC Cable
PIN 1
PIN 10
6
(DSR)
SHIELD
(GND)
(DTR)
(CTS)
(RTS)
5
4
8
7
(RXD)
(TXD)
2
3
5
(DTR)
SHIELD
6
(GND)
7
(DSR)
8
9
(RTS)
(CTS)
10 PIN MOD Plug
(Printer Signals)
4
3
(TXD)
(RXD)
PIN 9
PIN 1
USB Cable
Part Number AT17010-1; USB A to USB Mini B Cable
