46
ACQUAINTANCE WITH TRACTOR
E155 E156 E157
HAND BRAKE LEVER AND HITCH
LEVER FOR THE ONE-AXLE TRAILER
1. hand brake lever
2. hitch control lever for one-axle trailer
HYDRAULIC SYSTEM CONTROL
PANEL
The hydraulic system control panel (1) is
situated in the space of the right-hand
fender.
ADDITIONAL HYDRAULIC
DISTRIBUTOR CONTROL
The additional hydraulic distributor control
(2) is situated on the upper part of the
right-hand fender.
BATTERIES CUT-OFF SWITCH
During a long-term shutdown, re-
pairs, failure or crash remember
to disconnect the battery by
means of the battery cut-off
switch immediately.
The battery cut-off switch is located on
the left-hand tractor side in front of the
cab.
a - battery connected
b - battery disconnected
