Zte ZXR10 1800-2S User Manual

AboutThisManual
Purpose
Thismanualdescribesthehardwarestructure,components,systemcongurations,
performance,physicalparametersandsupportedboardsandcablesoftheZXR10ZSR
V2seriesrouters.
IntendedAudience
Thismanualisintendedfor:
lNetworkplanningengineers
lEquipmentinstallationengineers
lInstallationsupervisionengineers
WhatIsinThisManual
Thismanualcontainsthefollowingchaptersandappendixes.
Chapter1,HardwareOverview
DescribesthehardwareoverviewoftheZXR10ZSRV2
seriessrouters.
Chapter2,ZXR103800-8Chassis
Describesthestructure,components,slots,systempa-
rameters,powersupplies,andtheheatdissipationsys-
temoftheZXR103800-8chassis.
Chapter3,ZXR102800-4Chassis
Describesthestructure,components,slotlayout,system
parameters,powersupplies,andtheheatdissipationsys-
temoftheZXR102800-4chassis.
Chapter4,ZXR101800-2SChassis
Describesthestructure,components,slotlayout,system
parameters,powersupplies,andtheheatdissipationsys-
temoftheZXR101800-2Schassis.
Chapter5,ZXR102800-3EChassis
Describesthestructure,slotdeployment,systempa-
rameters,powermodules,andfanmodulesofaZXR10
2800-3Echassis.
Chapter6,ZXR101800-2EChassis
Describesthestructure,slotdeployment,systempa-
rameters,powermodules,andfanmodulesofaZXR10
1800-2Echassis.
Chapter7,MPFU
DescribestheMPFUsupportedbyallZXR10ZSRV2
seriesrouters.
Chapter8,GeneralProcessingBoards
DescribesgeneralprocessingboardsthattheZXR10
ZSRV2seriesrouterssupport.
I
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 1800-2S Specifications

General

Model	ZXR10 1800-2S
Category	Network Router
MAC Address Table	8K
VLANs	4K
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Power Supply	AC: 100V~240V, 50Hz~60Hz
