ZXR102900ESeriesCongurationGuide
lEdgeNode:Thenodeconnectswithmorethan2levelsinZESRringiscallededge
node.Theedgenodecanbetransmissionnode(contains2ports),masternode
(contains2ports)orassistantport(contains1port).
lAssistantNode:Theassistantportisalsoedgeport.Itisthetransmissionnodethat
hasonlyoneportintherelativesegment.Itmainlyassiststhemasternodetoachieve
serviceswitchingforthesegment.Asshownin“ZESRMulti-ringMulti-domainDesign
Figure”,majorringiscomposedofS1,S2,S3andS4.OfwhichS1ismasternode,
othersaretransmissionnode.Level1segment1iscomposedofS3,S4,S5andS6.
OfwhichS3andS4areassistantnodes,S5ismasternode,S6istransmissionnode.
Level1segment2iscomposedofS3,S4andS7.OfwhichS3andS4areassistant
nodes,S7ismasternode.
lSmart-linknode:Thesmart-linkisasimpleexpansionfortheformerZESRfunction
andrealizestheprotectionforkeyservicelink.Asshownin“SMART-LINK”,when
thelinkgoeswrong,itcanswitchautomaticallyandcarryoutmalfunctionresponsein
time.
IntroductiontoZESRFunction
lSingle-RingSingle-DomainZESR
àZESRDomain
ZESRdomainisanexampleofZESRprotocol.ItisinanEthernetringand
consistsofmasternode,transitnodeandcontrolVLAN.
Figure4-33ZESRrunningstatewhentheringis“completestate”
AsshowninFigure4-33,eachnodeisZXR102900Eswitch.Allthenodesform
aring.TheMASTERswitchisthemasternode.ZESRDomainsetsacontrol
VLANcomposedofalltheportsinthering.TheprotectedVLANmustcontain
alltheaboveports.ZESRDomainsetsamasterandmultitransitnodes.Each
nodeconnectswiththeringwithtwoports:primaryportandsecondaryport.
4-94
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2918E Specifications

General

VLANs	4K
Jumbo Frame	9K
Power Supply	AC: 100~240V, 50~60Hz
Operating Temperature	0°C~45°C
Storage Temperature	-40°C~70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5%~95% (non-condensing)
Power Consumption	<=25W
