15
- ELECTRONIC CONTROL MODELS
Table 3. Transformer Conguration
Note: This table is to be used for 8-tap and 5-tap transformers.
Figure 4. Secondary Transformer Coil
Table 5. Secondary Transformer Coil Conguration
Volts Line On Load On
208 COMMON & 208
SECONDARY 120V
240 COMMON & 240
277 COMMON & 277
480 COMMON & 480
Printed on 2/8/2018 9:05 AM CT
