EN – R1…R4 Quick installation guide 33
R1-
R4
R5
R6-
R9
EN
DA
DE
ES
FI
FR
IT
NL
PL
PT
RU
SV
TR
ZHZH
Install optional modules, if any
See chapter Electrical installation in ACS580-01 (0.75 to 250 kW, 1.0 to 350 hp)
hardware manual (3AXD50000044794 [English]).
Reinstall cover
See figure J on page 434.
1. Put the tabs on the inside of the cover top in their counterparts on the housing
(1a) and then press the cover at the bottom (1b).
2. Tighten the retaining screw with a screwdriver.
For start-up instructions, see chapter EN – Quick start-up guide on page 317.

ABB ACS580-01 Specifications

General

Number of Phases	3
Rated Power	0.75-250 kW
Enclosure Class	IP21, IP55
Mounting Type	Wall-mounted
Output Power Range	0.75-250 kW
Control Method	Scalar control, Vector control
Communication Protocols	Modbus RTU, PROFIBUS DP, CANopen
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Enclosure Rating	IP21, IP55
Dimensions	Varies by frame size
Weight	Varies by frame size
Product Type	Variable Frequency Drive
Output Voltage	0 to Input Voltage
Ambient Temperature Range	-10°C to +50°C
Cooling Method	Forced air cooling
