ABB ACS880-01 Series User Manual

95
Figures USA
A
3
4
5a
5b
6
7
7
L1 L2 L3 T1/U T2/V T3/W
UDC+
R+
UDC-
R-
L1 L2 L3
PE
ACS880-01
PE
U1
V1
W1
3 ~ M
Drive
type
ACS880-
01-
Air
flow
Losses
(ft
3
/
min)
(W) Type
U
1
= 230 V
115A-2 256 840 JJS-150
145A-2 256 940 JJS-200
170A-2 265 1260 JJS-250
206A-2 265 1500 JJS-300
274A-2 324 2100 JJS-400
U
N
= 480 V
096A-5 256 1295 JJS-150
124A-5 256 1440 JJS-200
156A-5 265 1940 JJS-225
180A-5 265 2310 JJS-300
240A-5 324 3300 JJS-350
260A-5 324 3900 JJS-400
302A-5 677 4200 JJS-400
361A-5 677 4800 JJS-500
414A-5 677 6000 JJS-600
U
N
= 525 V
061A-7 256 1295 JJS-110
084A-7 256 1440 JJS-150
098A-7 265 1940 JJS-150
119A-7 265 2310 JJS-200
142A-7 324 3300 JJS-250
174A-7 324 3900 JJS-300
210A-7 677 4200 JJS-400
271A-7 677 4800 JJS-400
B
C
ohm
M
3~
U1
V1
W1
PE
D
R6,R7,R9: M5×12 Torx T20
R8
: M5×20 Torx T20
2 N·m (17 lbf·in)

ABB ACS880-01 Series Specifications

General

Series	ACS880-01
Category	DC Drives
Control Method	Direct Torque Control (DTC)
Communication Options	Ethernet, Modbus, PROFIBUS, CANopen
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Cooling Method	Air-cooled
Enclosure	IP21
