Product identification (Nomenclature)
Table 1-6. Nomenclature
NOTES:
1. AV1 _ _ _ _ _ _is cFMus approved only for general purpose and non-incendive installations.
2. AV23 _ _ _ _ _ is cFMus approved only for general purpose and non-incendive applications.
AV27 _ _ _ _ _ is FM/CSA approved for use in explosion-proof or intrinsically safe applications.
3. High temperature Type AV1 positioners are only available without manifolds or position transmitters; however, gauge
blocks are permitted.
4. Explosionproof Type AV27 positioners are not available with position transmitters or manifolds.
5. The Type AV_ _ _ _ _ _N positioner comes with a NEMA 4X housing. To maintain the NEMA 4X classification, the
positioner shall be installed per drawing C258567 and suitable piping shall be attached to the vent opening and vented
in a manner to preclude the entrance of water under pressure, as from a hose. Additionally, the conduit connections shall
be suitable for a NEMA 4X rating.
6 AVI and AV2 POSITIONERS | SOI/AV12 R E V. A
Position 1 2 3 4 5 6 7 8 9 Characterizable Positioners
Type A V _ _ _ _ _ _ _
1 Characterizable Pneumatic Positioner
1
2 Characterizable 4 to 20-mA Input Positioner
2
(actuator moves to 0% or 100% upon loss of signal)
Input Signal
1 20.7 to 103.4 kPa (3.0 to 15.0 psig) (Type AV1)
2 20.7 to 186.2 kPa (3.0 to 27.0 psig) (Type AV1)
3 4 to 20 mA (Type AV2)
5 20.7 to 103.4 kPa (3.0 to 15.0 psig), high temperature applications (Type AV1)
3
6 20.7 to 186.2 kPa (3.0 to 27.0 psig), high temperature applications (Type AV1)
3
7 4 to 20 mA with explosionproof I/P converter (NEMA 7) (Type AV2)
4
Stroke/Rotary Motion (cam selection)
1 12.7 to 50.8 mm (0.5 to 20.0 in.) or 45° rotary motion
2 25.4 to 101.6 mm (1.0 to 4.0 in.) or 90° rotary motion
Manifold (includes filters)/Gauge Block
0 No manifold
Manifold with equalizing valve, filters and gauge ports (required for double
acting actuators with manual override)
3 Gauge block (gauge port only)
3
Position Transmitter
0 None (must be 0 for Types AV15, AV16 and AV27)
1 Potentiometric resistive output
2 4 to 20-mA output
Drive Shaft
0 Standard with feedback arm for linear motion
1 0.500-in. square end
2 0.342-in. square end for older DeZurik actuators
3 0.250 in. across flats (UP1 and UP2 after August, 1995)
4 0.375 in. square for DeZurik PowerRac® actuators
5 0.156 in. across flats for NAMUR rotary actuators
Other Options
0 Standard (no other options)
N NEMA 4X enclosure rating (when installed per drawing C258567)
5
P Performance Series — high pneumatic gain for large actuators
To Next Page
