ABB Busch-AudioWorld Busch-iDock 8218 U-500 User Manual

Operating Instructions
Busch-AudioWorld
®
Installation and electrical
connection
Operating Instructions | 1473-1-8319
— 10 —
Pos: 45 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Anschluss/ AudioVideo/Ins tallations-/ Ansc hlussmöglichkeiten - 8218 @ 31\ mod_1349177170853_1 5.docx @ 241339 @ 2223 @ 1
7.4.1 Installation / connection possibilities
Fig. 4: Use with Dock Connector or MP3 player
No.
Function
A Dock Connector (Apple interface)
B MP3 player 3.5 mm external line in/out
Fig. 5: Integration into Busch-AudioWorld
®
with the 8215 flush-mounted radio
No. Function
A 8218 U
B 8215 U
